Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables

Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables

Large Image :  Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables

Product Details:
Place of Origin: Shandong, China
Model Number: STGH8m
Payment & Shipping Terms:
Minimum Order Quantity: 500 square meters
Price: $6.90 - $20.00/square meters
Packaging Details: Steel frame will load into container directly.<br>Small accessories are packed by cartoon or bags.<br>Film is packed by bags.
Supply Ability: 50000 Square Meter/Square Meters per Month
Contact Now

Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables

Description
Features: Easy Assembled Manufacturer: Shine-tech
Instruction For Use: Installation Drawing Size: Large
Material: PE Type: Multi-Span Agricultural Greenhouses
Cover Material: Film Layer: Single
Product Name: Multi Span Film Greenhouse Application: Vegetable Fruits Flowers
Span Width: 8m Bay Width: 4m
Height: 4.0-8.0M Frame Material: Hot Dip Galvanized Steel Tube
Covering: 150/200micro Film Optional System: Cooling System.irrigation System.ventilation.etc
Advantage: Super Strong Resistance

Product Description
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 0
Agriculture Multispan Greenhouse Frame Vegetables Growing Multi Span film Greenhouse Tunnel
Multi span Plastic film Greenhouse is the most popular type of greenhouse, which uses very advanced science and technology, excellent materials and unique design skills to combine the previous single greenhouses together.
It is very flexible, clever use of space,it is stronger overall, better efficiency, and can save a lot of time, its use is very environmentally friendly and has an economic effect.
Suitable for high-value vegetables, fruits and flowers production, especially in extremely cold or hot area. Helpfully to produce high quality product and stable quantity against fluctuant outdoor environment.
Chinese Commercial Intelligent Multi-Span Film Greenhouse for Tomato
Product Name
Multi span Plastic film Greenhouse
Span width
8m/9.6m (customization)
Bay width
4m (customization)
Height of Greenhouse
4-8m (customization)
Covering
150/200 micron PE/PO Film
Wind load
45~55km/m2
Snow load
0.30~0.5KN/m2
Max. rainfall
140mm/h
Hanging load
15~30kg/m2
Optional system
Side ventilation, roof ventilation, shading system, cooling system, heating system, drip irrigation system, fogging system, hydroponic system, etc.
Details Images
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 1

Frame

The Frame Materials of greenhouse are hot dip galvanized steel and accessories.The structure is strong and durable.
The warranty period of frame is 15~20 years
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 2

Covering

Thickness: 120/150/200 microns. It has function of anti-UV, anti-aging and anti-drip.
Light transmission:>89%
Diffusion≤20%
UV transmission 300%-390%
Warranty: 4-5 years
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 3
Ventilation System
The greenhouse has both side ventilation and top ventilation system.
manual film roller and electric film motor are both available according to your requirement .
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 4
Anti-insect net
The Anti Insect Net is made by 100% virgin HDPE with stable UV. It provides protection from range of insects that can be harmful. This preventive method reduces the cost of pesticides to grow organic and natural cultivation.
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 5

Outside Shading System

Shading net: black round wire shade net with 75% shading rate.
Function: Electric control, adjust the light intensity to
improve the ecological environment in the greenhouse and lower the temperature.
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 6

Inside Shading System

Shading net: white aluminum foil shade net with 45% shading rate.
Function: Electric control, avoid direct sunlight to crops in summer, reduce the loss of indoor moisture; slow down heat loss in winter.
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 7

Cooling System

The cooling system including exhaust fan, cooling pad, and water pimp system.
The exhaust fans eject the air from the greenhouse , negative pressure formed in the greenhouse. The air enters the greenhouse through the cooling pads, resulting in the effects of temperature down.
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 8

Heating System

The most popular system is electric heating fan, and water boiler with heating blower.
We recommend electric heating fan for small greenhouse. water boiler and heating blower for large commercial greenhouse.

Wide application

Multi span film greenhouse is Widely for fruit(strawberry, cherry, grape, watermelon, muskmelon and so on), vegetable(tomato, cucumber, potato, eggplant, pepper, bean, celery, onion and so on), flowers, poultry farming, edible mushrooms cultivation and so on.
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 9
Project Case
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 10
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 11
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 12
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 13
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 14
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 15
Company Profile
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 16
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 17
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 18
Qingzhou Shine Tech Agriculture Equipment Co., LTD
Our Company is a high-tech agricultural equipment company integrating design, manufacturing, installation, after-sales, and Tunkey service.
Our main products are single tunnel greenhouse, multi span film greenhouse, PC greenhouse, Venlo glass greenhouse, Photovoltaic greenhouse, winter solar greenhouse, blackout greenhouse, hydroponic system, greenhouse film, cooling fan and pad, shading system, heating system, nursery bench, etc.
Our company persists in principal of quality first, builds wholesome quality management system, and strictly control the product quality. Our products have exported to the Philippines, Indonesia, India, Malaysia, Singapore, Thailand, Korea, Sri Lanka, Australia, French Polynesia, Uzbekistan, Kazakhstan, Turkmenistan, Armenia, UAE, Qatar, Saudi Arabia, Oman, Senegal, South Africa, Zimbabwe, Nigeria, Kenya, Ghana, Cameron, Democratic Republic of the Congo, Ethiopia, USA, Canada, Peru, Chile, Guyana, and so on, total more than 40 countries and places.
Our company is adhering to the business concept of "doing our best, pursuing outstanding, quality first and customer orientation", and trying our best to supply the best products and first-rate service to all the domestic and overseas customers. Warmly welcome you to our company for visiting and business negotiation.
If you prepare to build greenhouse, welcome to contact me and tell me your requirements, then I will give you a best design and quotation.
My Whatsapp/Wechat is same: +86 15966157097
EMAIL: shinetech2022@163.com
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 19
Packing & Delivery
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 20
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 21
Super Strong Resistance Agriculture Multispan Greenhouse Frame for Growing Vegetables 22
Why Choose Us
Q1:Can you design for us?
A: We can design the greenhouse according to your request.
Q2:How to ensure the quality of the products ?
A: Before delivery, our inspection department will examine and test the products thoroughly and carefully. Necessary test and certification can be obtained as your request.
You can let your friend or Third-party testing company to come for check product.
Q3:How can you ensure the legality and security during transaction?
A: We are a member of Alibaba Trade Assurance which is safeguarding buyer's payment to supplier to ensure supplier fulfill their obligations regarding delivery and product quality.
Q4:Do you provide installations and training service?
A: It is easy to install. We send install video or drawing to you. Or welcome visiting our factory. We will guide you how to install it in our factory
Q5:How long is delivery time?
A: 7-30days after getting deposit, it according to your order quantity.
